UNI-T UPO1084HD High-resolution Oscilloscope 80MHz 4Ch

The UNI-T UPO1082HD is a compact, high-resolution oscilloscope offering 80 MHz bandwidth and 12-bit ADC precision. Designed for professionals and educators, it features 100 Mpts memory depth, 1.25 GSa/s sample rate, and a 7-inch capacitive touchscreen with gesture support. Engineers can visualize waveform subtleties with Ultra Phosphor 3.0's 256-level intensity grading and capture rate up to 1M wfms/s. Six integrated instruments, protocol decoding, power analysis, and advanced triggering tools make this scope a flexible solution for embedded, analog, and power electronics.

Key Features

• 12-bit High Resolution – Offers 4096 quantization levels for enhanced signal detail
• 80 MHz Bandwidth – Optimized for power validation, analog sensor signals, and embedded systems
• 1.25 GSa/s Sample Rate – Clean signal capture of rapid transitions and glitches
• 4 Analog Channels – Streamlined setup for common test scenarios
• Ultra Phosphor 3.0 – 100,000 wfms/s standard, 1,000,000 wfms/s in sequence mode with 256-color intensity display
• 6-in-1 Instrument Integration – Includes oscilloscope, DVM, spectrum analyzer, frequency counter, protocol analyzer, and power analyzer
• Protocol Decoding Built-In – UART, I²C, SPI, CAN, LIN with time-correlated waveform display
• 100 Mpts Memory Depth – Allows long-duration captures with high fidelity
• Advanced FFT – 1M-point FFT with 4 traces, peak/marker tools, waterfall view
• Power Analysis Tools – Ripple, startup time, Rds(on), SOA, switching loss, and harmonics
• Type-C PD Power Input – Power from wall or portable charger
• SCPI & LAN/Web Control – Automate test routines or access remotely via browser
• Package Contents

UPO1084HD Oscilloscope

2 × UT-P05 Passive Probes (200 MHz)

USB 2.0 Cable (UT-D14)

Type-C PD Power Adapter

User Manual & Calibration Certificate
